KTM 690 Enduro 2021 to 2024 EURO 5 - FLAWLESS ECU Performance Flash

More power and torque?
We at FLAWLESS Industries offer you a software optimization of your ECU with our exclusive FLAWLESS ECU Performance Flash for your KTM 690 ENDURO 2021 to 2024 EURO 5, featuring characteristics that will put you in the fast lane. And all this without additional hardware - just by flashing your control unit.

As of now, we can offer the so-called Full Maps-switch in our 2024 version! We at FLAWLESS Industries continuously develop our FLAWLESS ECU Performance Flashes to offer you the best possible solution for your KTM 690 ENDURO. With our Full Mapsswitch, you can now not only set the Linear Throttle to one mapping or riding mode, but the complete FLAWLESS ECU Performance Flash - including all options such as lambda control, deceleration fuel cut-off, and, of course, the power increase.

• Performance Increase: We individually write and adapt the tuning software or optimization for your KTM 690 ENDURO to your installed hardware. This achieves an additional power output of approx. 5 to 8 HP and 10 to 12 NM of torque. In addition to the increased power, our FLAWLESS ECU Performance Flash improves rideability: The power delivery of your 690 ENDURO becomes significantly more homogeneous and smoother. The annoying constant speed jerking of your KTM also completely disappears after the ECU optimization, giving you a significant increase in rideability. Furthermore, our performance increase eliminates the well-known torque dip of your KTM at approx. 4500 rpm. The injection maps are also adjusted by us so that the air-fuel ratio values of your 690 ENDURO are now in the optimal range. This also achieves thermal relief for the exhaust valves and cylinder heads due to the resulting lower exhaust gas temperatures.

• FLAWLESS Performance Kit: Experience a whole new dimension of driving dynamics and power delivery with our FLAWLESS ECU Performance Flash and the associated FLAWLESS Performance Kit. Our goal was to develop a product that offers you maximum performance increase and improved rideability with minimal effort – and that's exactly what we achieved:
– More Power and Torque: In combination with our FLAWLESS ECU Performance Flash, the Performance Kit increases the peak power of your KTM 690 Enduro by an impressive 9 to 10 HP. In the mid-range, you also benefit from an increase in torque of 17 to 18 NM.

• FLAWLESS Gear Switch: With our FLAWLESS Gear Switch, your 690 Enduro gets an additional riding mode – the Safemap. This offers you a third mode, which is automatically activated when starting normally. In this mode, your 690 Enduro runs with the original mapping (A2 or A), regardless of which map you have selected via the FLAWLESS Power Mapswitch. However, as soon as you start the ignition with the second gear engaged, the engine warning light in your speedometer flashes. This signals that the FLAWLESS ECU Performance Flash is now active in your individual configuration. After starting, the engine warning light goes out and you can use the full power of the ECU Performance Flash and now have both riding modes of the map switch of your 690 Enduro available. Please indicate in the comment field at checkout whether you want the Safemap. If yes, whether the Safemap should be configured as a production A-map or production A2-map.

• FLAWLESS Power Mapswitch: Full attack at the touch of a button? With this option, you can switch between 2 mappings on the handlebar of your KTM 690 Enduro, so that you have the standard mapping on Map 1 and the FLAWLESS ECU Performance Flash with all desired functions on Map 2!

• FLAWLESS Quickshifter: Discover our completely newly developed FLAWLESS Quickshift algorithm, which gives your 690 Enduro incomparable shifting speed and sportiness! We have not only refined the interruption times but optimized the entire Quickshifter algorithm to offer you the ultimate Quickshifter experience. For an even more intense riding experience, we optionally offer shift acoustics in Map 2, which gives every gear change an impressive soundscape - perfect for all who seek maximum sportiness! Important - shift acoustics are not possible with a catalyst configuration.

• Hardcut Limiter: With the Hardcut Limiter, the standard rev limiter of your Enduro becomes a true race limiter, providing an unmistakable riding experience. Flames from the exhaust are guaranteed with the Hardcut Limiter!

Important: The Hardcut Limiter may only be used in conjunction with an exhaust system without a catalytic converter and without a DB killer. Please note that increased engine wear cannot be ruled out with excessive use.

• Optimized Fan Temperature: Your engine stays cooler! We lower the fan activation temperature from 100°C to 95°C – for earlier cooling, more thermal stability, and less thermal stress for your engine.

• Linear Throttle: The previous throttle response is not good enough for you? Upon request, we program your throttle grip characteristic 1 to 1 with the throttle body characteristic - 50% throttle grip means 50% throttle body position. For the ultimate throttle response of your KTM 690 ENDURO!

• Pops and Bangs: Give your KTM 690 ENDURO the final acoustic touch. Through our optimization, we can configure the deceleration fuel cut-off individually according to your wishes and the installed setup of your KTM 690 ENDURO, and, if desired, also assign it to the respective riding modes. Important - with a setup including a catalytic converter, only a deceleration burble is possible.

You can customize the optimization or mapping directly when ordering according to your wishes. The selection fields are available for this.
Please indicate in the comment field at checkout when ordering which setup you are running. It is important to specify which rear silencer (LeoVince, Remus, Austin Racing, Arrow, Akrapovic, ...), which air filter (K&N sport air filter, BMC, Rade Garage, ...) and air filter cover (open air filter / Powerparts cover, perforated cover, ...) you use, and whether you have a catalytic converter installed.

Process:
1. Order the FLAWLESS ECU Performance Flash or your ECU software optimization for your KTM 690 ENDURO with the desired options.
2. Send your control unit or ECU well-packaged to us (FLAWLESS Industries - Pilatusring 20, 91353 Hausen, Germany)
3. We process the software of your control unit on the day of arrival and usually return it to you within 24 hours.
4. Unpack, connect, and ride.

Important
To offer you this service, it is necessary that you send us your removed control unit from your vehicle. As soon as we have received it, we will individually adapt your FLAWLESS ECU Performance Flash. We usually return your control unit with the modified software within 24 hours so that you can reinstall it as quickly as possible.
To achieve the specified performance, it is necessary to use an aftermarket rear silencer (LeoVince, Remus, Austin Racing, Arrow, Akrapovic, etc.), a sport air filter (K&N sport air filter, BMC, Rade Garage, etc.), and the Powerparts air filter cover or perforated cover. The upgrade air filter we offer is a K&N sport air filter. The control unit will not be damaged or opened. The FLAWLESS ECU Performance Flash is not visible from the outside. KTM testers work without restrictions. The software number remains unchanged.

- Suitable for KTM 690 ENDURO models from 2021 to 2024 (EURO 5)
- Simple and fast service
- Maximum performance increase and improved handling
